Frame & Fork
Frame: Alpha Gold Aluminium, internal cable routing, rack & mudguard mounts, post mount disc, kickstand mount, 135x5mm QR
Fork: FX steel, flat-mount disc, rack mounts, 410mm axle-to-crown, ThruSkew 5mm QR
Wheels & Tyres
Front Hub: Formula DC-20, alloy, 6-bolt, 5x100 mm QR
Rear Hub: Formula DC-22, alloy, 6-bolt, Shimano 8/9/10 freehub, 135x5 mm QR
Front Skewer: 139x5 mm bolt-on
Rear Skewer: 152 x 5 mm QR
Rims: Bontrager Connection, double-wall, 32-hole, 20 mm width, Schrader valve
Tyres: Bontrager H2 Comp, wire bead, 30 tpi, 700x35 mm
Gears & Drivetrain
Front Shifter: Shimano EF500, 2-speed
Rear Shifter: Shimano EF500, 8-speed
Front Derailleur: Shimano Tourney TY606, 31.8/34.9 mm clamp, top swing, dual pull
Rear Derailleur: Shimano Acera M3020-8, 40T max cog
Chainset: Forged alloy, 46/30, 170 mm length
Bottom Bracket: Sealed cartridge, 68 mm
Cassette: Shimano 8-speed, 12-32T
Chain: KMC Z8.3
Components
Handlebars: Bontrager Riser, steel, 25.4 mm, 30 mm rise
Stem: Bontrager alloy, 25.4 mm clamp, 10-degree
Grips: Trek Line Ergonomic Comp, lock-on
Saddle: Bontrager Sport
Seatpost: Bontrager alloy, 27.2 mm, 12 mm offset
Brakes
Brakes: Tektro MD-U310 mechanical disc
Rotors: Tektro wave, 6-bolt, 160 mm
Weight
Weight Limit: This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb).
