SPECIFICATIONS
FRAMESET
Frame: Alpha 200 series aluminium, tapered head-tube, BB86.5, flat-mount disc brakes, 12mm thru-axle, internal cable routing, w/rack mounts and hidden fender mounts
Fork: Checkpoint carbon disc, tapered steerer, flat-mount disc brakes, rack mounts, hidden mudguard mounts, 12 mm thru-axle
WHEELS
Front Hub: Formula alloy disc, 12 mm thru-axle, 24h
Rear Hub: Formula alloy disc, 12 mm thru-axle, 24h
Rims: Bontrager Affinity, Tubeless Ready, 24h
Tyres: Bontrager R1 Hard-Case Lite, 700x32c
Max Tyre Size: 38c Bontrager tyres (with at least 4 mm of clearance to frame)
DRIVETRAIN
Shifters: Shimano Tiagra, 10-speed
Front Derailleur: Shimano Tiagra
Rear Derailleur: Shimano Tiagra
Crank: Shimano Tiagra, 50/34 (compact)
Bottom Bracket: Sealed cartridge
Cassette: Shimano Tiagra, 11-32, 10-speed
Chain: Shimano Tiagra
Pedals: Not included
COMPONENTS
Saddle: Bontrager Arvada Comp, steel rails
Seatpost: Bontrager-Approved, alloy, 27.2 mm
Handlebar: Bontrager Comp VR-C, 31.8 mm
Bar Tape: Bontrager Tape
Stem: Bontrager Elite, 31.8 mm, 7-degree, w/computer and light mounts
Headset: Integrated, cartridge bearing, sealed, 1-1/8˝ top, 1.5˝ bottom
Brakeset: Shimano RS405 flat-mount hydraulic disc
WEIGHT
Weight: 56cm – 10.56 kg/23.28 lbs
Weight Limit: This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 125 kg (275 lb).
