SPECIFICATIONS
Frame & Fork
Colour: Matt Olive with Khaki & Burnt Orange
Frame: 6061 Alloy, Hydro Formed T6 Aluminium, Multi Butted, SCR, Tapered Headtube, Get A Grip Seat Clamp System, Internal Cable Routing with BBX and Chainstay Post Mount Dropouts 10mm x 141mm Boost
Fork: RockShox Recon RL 27.5", 120mm Travel, 37mm Offset, Solo Air, Fast Black Coating, Adjustable Rebound, Tapered Alloy Steerer, 110mm x 15mm Boost, Maxle Lite
Rear Shock: N/A
Headset: FSA No. 57B Orbit ZS, 1 1/2" Lower and 1 1/8" Upper Caged Bearings
Wheels & Tyres
Front Hub: Alloy, Double Sealed Cartridge Bearings, 15mm x 110mm Boost Through Axle, 32 Hole
Rear Hub: Alloy, Cup & Cone, Double Seal, 10mm x 141mm QR Boost, with stealth axle, 32 Hole
Rims: WTB ST i27 TCS 2.0 System, Pinned Joint, Tubeless Ready, 32 Hole
Spokes : DT Swiss Champion 2.0mm, Black Stainless, Brass Nipples
Front Tyre: Maxxis High Roller II TR 27.5"x 2.4" 60TPI, EXO Sidewall Protection, 3C Maxx Terra
Rear Tyre: Maxxis Forekaster TR 27.5" x 2.35" 60TPI, EXO Sidewall Protection, Dual Compound
Gears & Drivetrain
Shift Levers: Shimano Deore SL-M4100, 10 Speed
Cassette: Shimano CS-M4100, 11-46, 10 Speed
Front Mech: N/A
Rear Mech: Shimano Deore RD-M5120-SGS, Shadow Plus, 10 Speed
Chain: SunRace, 10 Speed
Crankset: Whyte, Forged 2pcs Cranks, Direct Mount 32T Narrow/Wide Chainring, 170mm, 10 Speed
Bottom Bracket: BSA, Cartridge Bearings, 73mm
Components
Seatpost: Whyte 6061 Alloy, 15mm Offset, 30.9mm x S/M 350mm, L/XL 400mm, 2 Bolt Clamp
Saddle: Whyte Custom, Triple Panel Design
Handlebar: Whyte 6061 Alloy, 15mm Rise, 31.8mm, S 760mm Wide, M/L/XL 780mm Wide
Stem: Whyte Alloy, 40mm Extension
Grips: Whyte Lock-On V Grip
Pedals: Fibre Reinforced Composite Platform
Brakes
Brake Levers: Shimano MT-402
Front Brake: Shimano MT-400, Hydraulic, 180mm Rotor
Rear Brake: Shimano MT-400, Hydraulic, 180mm Rotor
Weight
Weight: TBC
