Frame: Alpha Gold Aluminium, tapered head tube, internal derailleur and dropper post routing, rack and kickstand mount, Boost141, 5 mm QR
-
Fork: Size: XS - RockShox 35 Gold, Solo Air spring, Motion Control damper, lockout, tapered steerer, 44 mm offset, Boost110, 15 mm Maxle Stealth, 100 mm travel
Size: S, M, M/L, L, XL, XXL - RockShox 35 Gold, Solo Air spring, Motion Control damper, lockout, tapered steerer, 44 mm offset, Boost110, 15 mm Maxle Stealth, 120 mm travel
-
Front Hub: Bontrager alloy, sealed bearing, alloy axle, 6-bolt, Boost110, 15 mm thru axle
-
Rear Hub: Formula DCL-141Q, sealed bearing, 6-bolt, Shimano 10 freehub, Boost141, 5 mm QR
-
Rims: Bontrager Line 40, Tubeless Ready, 28-hole, 40 mm width, Presta valve
-
Spokes: 14 g, stainless
-
Tyres: Size: XS, S, M, M/L, L, XL, XXL - Maxxis Rekon, tubeless, 60 tpi, 27.5x2.80"
Size: XS, S, M, M/L, L, XL, XXL - Bontrager XR3 Team Issue, Tubeless Ready, Inner Strength sidewall, aramid bead, 120 tpi, 27.5x2.80"
-
Shifter: SRAM NX Eagle, 12-speed
-
Rear Derailleur: SRAM NX Eagle
-
Crank: Size: XS, S - Truvativ Descendant 6k Eagle, GXP, 30T alloy ring, Boost, 170 mm length
Size: M, M/L, L, XL, XXL - Truvativ Descendant 6k Eagle, GXP, 30T alloy ring, Boost, 175 mm length
-
Bottom Bracket: Truvativ Powerspline, 73 mm, threaded cartridge, 118 mm spindle
-
Cassette: SRAM PG-1230 Eagle, 11-50, 12-speed
-
Chain: SRAM NX Eagle, 12-speed
-
Pedals: VP-536 nylon platform
-
Saddle: Bontrager Arvada, steel rails, 138 mm width
-
Seatpost: Size: XS, S - TranzX JD-YSP18, 100 mm travel, internal routing, 31.6 mm, 361 mm length
Size: M, M/L, L, XL, XXL - TranzX JD-YSP18, 130mm travel, internal routing, 31.6 mm, 425 mm length
-
Handlebar: Size: XS - Bontrager alloy, 31.8 mm, 15 mm rise, 720 mm width
Size: S, M, M/L, L, XL, XXL - Bontrager alloy, 31.8 mm, 15 mm rise, 750 mm width
-
Grips: Bontrager XR Trail Comp, nylon lock-on
-
Stem: Size: XS, S, M - Bontrager Rhythm Comp, 31.8mm, Knock Block, 0-degree, 50 mm length
Size: M/L, L, XL, XXL - Bontrager Rhythm Comp, 31.8mm, Knock Block, 0-degree, 60 mm length
-
Headset: Semi-integrated, cartridge bearing, 1-1/8" top, 1.5" bottom
-
Brakes: Shimano hydraulic disc, MT501 lever, MT500 caliper
-
Weight: M - 14.55 kg / 32.07 lbs (with tubes)
-
Weight limit: This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb).
