Frame & Fork
Frame: 6061 Alloy, Hydro Formed T6 Aluminium, Multi Butted, Internal
Cable Routing with BBX and Custom Whyte Dropouts, Chain Stay
Kick Stand Mount
Fork: Whyte Straight Bladed 6061 Alloy, Alloy Tapered Steerer, Internal Cable Routing, 12mm Thru Axle, Post Mount with Single Eyelets for Mudguards
Wheels & Tyres
Front Hub: Alloy, Cup & Cone, Double Seal, 32 Hole
Rear Hub: Alloy, Cup & Cone, Double Seal, 32 Hole
Rims: Whyte Disc Road, Low Profile, 23mm Wide, Tubeless Compatible,
3M Reflective Decals, 32 Hole Rear and 32 Hole Front
Spokes: 2.0mm, PG, Black Stainless, Brass Nipples
Front Tyre: Vittoria Terreno Zero 700 x 37c, Puncture Protection
Rear Tyre: Vittoria Terreno Zero 700 x 37c, Puncture Protection
Gears & Drivetrain
Shifters: Microshift SL-M859-R, Trigger Shifter, 9 Speed
Rear Mech: Microshift RD-M46S, 9 Speed
Crank: Alloy, 42T Chainring with Alloy Chain Guard
Bottom Bracket: Square Interface, Cartridge Bearings, 68mm
Cassette: Microshift CS-H092, 11-36, 9 Speed
Chain: Sunrace, 9 Speed
Brakes
Front Brake: Tektro HD-M275, Hydraulic, 160mm Rotor, Internal Routing
Rear Brake: Tektro HD-M275, Hydraulic, 160mm Rotor, Internal Routing
Brake Levers: Tektro HD-M275
Components
Saddle: Whyte Custom
Seatpost: Whyte 6061 Alloy, 25mm Offset, 27.2mm x S/M/L 350mm, XL
400mm, 2 Bolt Clamp
Handlebar: Whyte 6061 Alloy, 25mm Rise, 31.8mm, 620mm Wide
Grips: Whyte Custom Dual Density Lock-on
Stem: Whyte Alloy, S 45mm, M/L/XL 60mm
Headset: FEIMIN H809C, Integrated Road, 1 1/8” Sealed Cartridge Bearings,
41mm Diameter
Pedals: Fibre Reinforced Composite Platform
